PRODUCTION
产品项目 |
MM |
INCH/AWG |
|
Single wire size
单线径 |
0.05-2.5 |
44 -11 |
|
Bifilar wire size
双线径 |
2×1.8 |
2×131/2 |
|
Finished core O.D.
完成外径 |
5.0-320 |
0.2 – 13 |
|
Finished core I.D.
完成内径 |
From 1.5 |
From 0.06 |
|
Finished core height
完成铁心高度 |
Upto 150 |
Upto 5.9 |
|
Tape size
包带尺寸 |
4 -30 |
0.05-1.18 |
|
TECHNICAL DATA/技术数据:
|
COMBINATIONS/机器结合 |
|
21 Interchangeable heads/可互换机头 |
|
4 Slider heads /边滑器式机头 VU10, VU20,VU30, VU40 |
|
5 Gear rack heads/齿条式机头VU0,VU1, VU2, VU3,VU4 |
|
5Belt heads/皮带式机头 VU60,VU100, VU200,VU200-V,VU300 |
|
7Taping head/包带机头 VU0/B,VU1/B, VU2/B,VU3/B VU4/B VU200/B,VU300/B |
|
6 Roller tables/滚子台架 VU111,VU111-V, VU112,VU222, VU222-V,VU332 |
| |
l CONTROLLER控制器
PLC CONTROL WITH SOFTWARE LANGUAGES: EN.CH./ PLC可编程控制器,中英文两种操作语言
l DISPLAY显示
LCD-DISPLAY WITH BACKGROUND ILLUMINATION: CONTINUOUS READ OUT OF OPERATION DETAILS
/液晶显示速度及操作信息
l PRESETS设定
60 PROGRAMS, / 60种程序
EACH PROGRAM CONTAINS OF 8 SEQUENCES /每个程序包含8段
l PROGRAMMING程序
USER FRIENDLY TEXT COMMANDS/采用简单文本命令设定
l DATA MEMORY AND OUTPUT
数据存储与输出
INTERFACES FOR PC
INTERFACE FOR SOFTWARE UPDATES/PC数据线输入/软件可以升级
l WINDING SPEED绕线速度
UP TO 1800 RPM 最高可达1800RPM
SEPARATELY PROGRAMMABLE LOAD SPEED
SEPARATELY PROGRAMMABLE WIND SPEED/可设定储线速度和绕线速度
l CORE DRIVE铁芯驱动
STEPPER MOTOR 0,30 KW/步进马达0.30KW
l WIRE PITCH CONTROL线距控制
FULLY AUTOMATIC PITCH CHANGE,
PROGRAMMABLE IN STEPS OF 0,001mm/线距可自动调节
l CORE INDEX & REVERSE CONTROL
铁芯正反转
FULLY AUTOMATIC/全自动
l ACCELERATION & DECELLERATION
增速、减速
FULLY AUTOMATIC/全自动
l STOPS FOR TAPS抽头停机
AUTOMATIC/全自动
l SECTOR & BANK WINDING CONTROL
FULLY AUTOMATIC/全自动
l WINDING HEAD DRIVE绕线机头驱动
SERVO MOTOR 0,8 KW /伺服马达0,8 KW
l TAPING OPERATION 包带操作
FULLY AUTOMATIC /全自动
l SUPPLY VOLTAGES提供电源
230 (110 AND 240) VOLT, 50 HZ AC
l MACHINE SIZE AND WEIGHT
机器尺寸及重量
800×700 MM 110 KG NET, 130 KG GROSS |
