12.1” TFT-LCD
800x600
262K
350
H:140° / V :110°
50,000hrs
Sealed analog resistive
80%
DC 11~32V
0~50 oC
-20~60 oC
10~90% @40oC non-condensing
Meet CE/FCC Class A

Intel® Atom™ N270 1.6 GHz built-in, FSB 533 MHz
1 x 200-pin SO-DIMM socket, support 533 MHz up to 2GB
DDR2 SDRAM
Intel® 945GSE + ICH7M
● 4 x USB ports
● 2 x RJ-45 ports (GbE)
● 2 x DB-9 (COM1/3, RS-232)
● 1 x DB-9 (COM2, RS-232/422/485, default RS-232)
● 1 x VGA port
● 1 x Audio, Line-out
● 1 x DC power input
1 x 2.5” SA TA HDD, 1 x external CF slot
None
Windows® CE 5.0, XP Pro, XP Embedded, Windows ® 7

Plastic molding front panel and metal housing
