型号 |
测试点数 |
AC/DC 耐压测试 |
DC 绝缘测试／阻抗范围 |
2/4 线接地测试 |
器件测试 |
外观 |
|
Low voltage cable tester
SYNOR1809 |
64-16000 |
No |
No |
1Ω-250Ω
10mΩ-250Ω |
resistance, diode, capacitor, shielding |
Distributed modules
(satelittes) |
|
High voltage cable tester
SYNOR1202 |
64-256
Multi-contact relays |
Up to 1500 VAC
2000 VDC
(AC hipot option) |
20-2000V DC
50kΩ-1GΩ |
1Ω-250Ω
1mΩ-250Ω |
resistance, diode, capacitor, inductance, shielding |
Small rack |
|
High voltage cable tester
SYNOR4202 |
64-100000
Multi-contact relays |
Up to 1500 VAC
2000 VDC
(AC hipot option) |
20-2000V DC
50kΩ-1GΩ |
1Ω-250Ω
1mΩ-250Ω |
resistance, diode, capacitor, inductance, shielding |
19 inches rack |
|
High voltage cable tester
SYNOR4203 |
64-100000
Multi-contact relays |
Up to 1500 VAC
2000 VDC
(AC hipot option) |
20-2000V DC
50kΩ-1GΩ |
1Ω-250Ω
1mΩ-250Ω |
resistance, diode, capacitor, inductance, GMOV, transorb, shielding |
19 inches cabinet |
|
High voltage cable tester
SYNOR 4207P |
64-100000
2 relays per point |
Up to 5000 VAC
6000 VDC
(AC hipot option) |
20-4200V DC
50kΩ-1GΩ |
1-250Ω
1mΩ-250Ω |
resistance, diode, capacitor, inductance, shielding |
19 inches rack |
|
High voltage cable tester
SYNOR 4208P |
64-100000
2 relays per point |
Up to 5000 VAC
6000 VDC
(AC hipot option) |
20-4200V DC
50kΩ-1GΩ |
1-250Ω
1mΩ-250Ω |
resistance,
diode, capacitor, inductance, GMOV,
transorb,
shielding |
19 inches cabinet |
|
High voltage cable tester
SYNOR4209 |
64-100000
2 relays per point /Multi-contact relays |
Up to 5000 VAC
6000 VDC
(AC hipot option) |
20-4200V DC
50kΩ-1GΩ |
1-250 Ω
1mΩ-250Ω |
resistance, diode, capacitor, inductance, shielding |
Distributed modules
(satelittes) |
