Acti9系列微型断路器价格表
iC65N 小型断路器
标准GB10963/IEC60898
额定电流1~63A
分断能力6000A
极数1,2,3,4
脱扣曲线B,C,D
References Description 含税面价
A9F17101 iC65N 1P B1A 93.0
A9F17102 iC65N 1P B2A 58.5
A9F17103 iC65N 1P B3A 54.0
A9F17104 iC65N 1P B4A 54.0
A9F17106 iC65N 1P B6A 44.8
A9F17110 iC65N 1P B10A 32.9
A9F17116 iC65N 1P B16A 32.9
A9F17120 iC65N 1P B20A 32.9
A9F17125 iC65N 1P B25A 36.8
A9F17132 iC65N 1P B32A 36.8
A9F17140 iC65N 1P B40A 44.8
A9F17150 iC65N 1P B50A 54.0
A9F17163 iC65N 1P B63A 59.2
A9F17201 iC65N 2P B1A 213.1
A9F17202 iC65N 2P B2A 135.6
A9F17203 iC65N 2P B3A 125.1
A9F17204 iC65N 2P B4A 125.1
A9F17206 iC65N 2P B6A 106.7
A9F17210 iC65N 2P B10A 80.6
A9F17216 iC65N 2P B16A 80.6
A9F17220 iC65N 2P B20A 80.6
A9F17225 iC65N 2P B25A 88.4
A9F17232 iC65N 2P B32A 88.4
A9F17240 iC65N 2P B40A 108.1
A9F17250 iC65N 2P B50A 122.5
A9F17263 iC65N 2P B63A 130.4
A9F17301 iC65N 3P B1A 277.7
A9F17302 iC65N 3P B2A 199.7
A9F17303 iC65N 3P B3A 184.5
A9F17304 iC65N 3P B4A 184.5
A9F17306 iC65N 3P B6A 158.1
A9F17310 iC65N 3P B10A 127.7
A9F17316 iC65N 3P B16A 127.7
A9F17320 iC65N 3P B20A 127.7
A9F17325 iC65N 3P B25A 138.2
A9F17332 iC65N 3P B32A 138.2
A9F17340 iC65N 3P B40A 164.6
A9F17350 iC65N 3P B50A 184.5
A9F17363 iC65N 3P B63A 197.5
A9F17401 iC65N 4P B1A 413.2
A9F17402 iC65N 4P B2A 270.8
A9F17403 iC65N 4P B3A 250.2
A9F17404 iC65N 4P B4A 250.2
Page 1 of 76
A9F17406 iC65N 4P B6A 210.8
A9F17410 iC65N 4P B10A 171.3
A9F17416 iC65N 4P B16A 171.3
A9F17420 iC65N 4P B20A 171.3
A9F17425 iC65N 4P B25A 184.5
A9F17432 iC65N 4P B32A 184.5
A9F17440 iC65N 4P B40A 217.2
A9F17450 iC65N 4P B50A 243.6
A9F17463 iC65N 4P B63A 263.4
A9F18101 iC65N 1P C1A 61.5
A9F18102 iC65N 1P C2A 57.3
A9F18104 iC65N 1P C4A 53.0
A9F18106 iC65N 1P C6A 44.0
A9F18110 iC65N 1P C10A 32.1
A9F18116 iC65N 1P C16A 32.1
A9F18120 iC65N 1P C20A 32.1
A9F18125 iC65N 1P C25A 36.1
A9F18132 iC65N 1P C32A 36.1
A9F18140 iC65N 1P C40A 44.0
A9F18150 iC65N 1P C50A 53.0
A9F18163 iC65N 1P C63A 58.2
A9F18201 iC65N 2P C1A 138.3
A9F18202 iC65N 2P C2A 132.8
A9F18204 iC65N 2P C4A 122.7
A9F18206 iC65N 2P C6A 104.7
A9F18210 iC65N 2P C10A 78.7
A9F18216 iC65N 2P C16A 78.7
A9F18220 iC65N 2P C20A 78.7
A9F18225 iC65N 2P C25A 86.4
A9F18232 iC65N 2P C32A 86.4
A9F18240 iC65N 2P C40A 105.9
A9F18250 iC65N 2P C50A 120.1
A9F18263 iC65N 2P C63A 127.9
A9F18301 iC65N 3P C1A 206.8
A9F18302 iC65N 3P C2A 195.8
A9F18304 iC65N 3P C4A 180.8
A9F18306 iC65N 3P C6A 155.0
A9F18310 iC65N 3P C10A 125.2
A9F18316 iC65N 3P C16A 125.2
A9F18320 iC65N 3P C20A 125.2
A9F18325 iC65N 3P C25A 135.6
A9F18332 iC65N 3P C32A 135.6
A9F18340 iC65N 3P C40A 161.3
A9F18350 iC65N 3P C50A 180.8
A9F18363 iC65N 3P C63A 193.8
A9F18401 iC65N 4P C1A 276.9
A9F18402 iC65N 4P C2A 265.6
A9F18404 iC65N 4P C4A 245.5
A9F18406 iC65N 4P C6A 206.6
A9F18410 iC65N 4P C10A 167.9
A9F18416 iC65N 4P C16A 167.9
A9F18420 iC65N 4P C20A 167.9
A9F18425 iC65N 4P C25A 180.8
Page 2 of 76
A9F18432 iC65N 4P C32A 180.8
A9F18440 iC65N 4P C40A 213.1
A9F18450 iC65N 4P C50A 238.8
A9F18463 iC65N 4P C63A 258.2
A9F19101 iC65N 1P D1A 81.7
A9F19102 iC65N 1P D2A 81.7
A9F19104 iC65N 1P D4A 75.3
A9F19106 iC65N 1P D6A 54.3
A9F19110 iC65N 1P D10A 45.2
A9F19116 iC65N 1P D16A 45.2
A9F19120 iC65N 1P D20A 45.2
A9F19125 iC65N 1P D25A 51.6
A9F19132 iC65N 1P D32A 51.6
A9F19140 iC65N 1P D40A 59.5
A9F19150 iC65N 1P D50A 69.0
A9F19163 iC65N 1P D63A 79.5
A9F19201 iC65N 2P D1A 186.3
A9F19202 iC65N 2P D2A 186.3
A9F19204 iC65N 2P D4A 172.2
A9F19206 iC65N 2P D6A 132.3
A9F19210 iC65N 2P D10A 107.0
A9F19216 iC65N 2P D16A 107.0
A9F19220 iC65N 2P D20A 107.0
A9F19225 iC65N 2P D25A 121.8
A9F19232 iC65N 2P D32A 121.8
A9F19240 iC65N 2P D40A 138.9
A9F19250 iC65N 2P D50A 158.8
A9F19263 iC65N 2P D63A 185.2
A9F19301 iC65N 3P D1A 272.4
A9F19302 iC65N 3P D2A 272.4
A9F19304 iC65N 3P D4A 251.5
A9F19306 iC65N 3P D6A 185.2
A9F19310 iC65N 3P D10A 165.4
A9F19316 iC65N 3P D16A 165.4
A9F19320 iC65N 3P D20A 165.4
A9F19325 iC65N 3P D25A 178.8
A9F19332 iC65N 3P D32A 178.8
A9F19340 iC65N 3P D40A 185.2
A9F19350 iC65N 3P D50A 211.6
A9F19363 iC65N 3P D63A 245.0
A9F19401 iC65N 4P D1A 337.0
A9F19402 iC65N 4P D2A 337.0
A9F19404 iC65N 4P D4A 311.1
A9F19406 iC65N 4P D6A 264.8
A9F19410 iC65N 4P D10A 245.0
A9F19416 iC65N 4P D16A 245.0
A9F19420 iC65N 4P D20A 245.0
A9F19425 iC65N 4P D25A 251.5
A9F19432 iC65N 4P D32A 251.5
A9F19440 iC65N 4P D40A 264.8
A9F19450 iC65N 4P D50A 304.6
A9F19463 iC65N 4P D63A 350.9
Page 3 of 76
iC65N-K 小型断路器
标准GB10963/IEC60898
额定电流6~32A
分断能力6000A
极数1,2,3,4
脱扣曲线C
References Description
A9K58106 iC65N-K 1P C6A 41.5
A9K58110 iC65N-K 1P C10A 30.3
A9K58116 iC65N-K 1P C16A 30.3
A9K58120 iC65N-K 1P C20A 30.3
A9K58125 iC65N-K 1P C25A 34.1
A9K58132 iC65N-K 1P C32A 34.1
A9K58206 iC65N-K 2P C6A 98.6
A9K58210 iC65N-K 2P C10A 74.1
A9K58216 iC65N-K 2P C16A 74.1
A9K58220 iC65N-K 2P C20A 74.1
A9K58225 iC65N-K 2P C25A 81.4
A9K58232 iC65N-K 2P C32A 81.4
A9K58306 iC65N-K 3P C6A 146.0
A9K58310 iC65N-K 3P C10A 117.9
A9K58316 iC65N-K 3P C16A 117.9
A9K58320 iC65N-K 3P C20A 117.9
A9K58325 iC65N-K 3P C25A 127.7
A9K58332 iC65N-K 3P C32A 127.7
A9K58406 iC65N-K 4P C6A 194.5
A9K58410 iC65N-K 4P C10A 158.1
A9K58416 iC65N-K 4P C16A 158.1
A9K58420 iC65N-K 4P C20A 158.1
A9K58425 iC65N-K 4P C25A 170.3
A9K58432 iC65N-K 4P C32A 170.3
iC65H小型断路器
标准GB10963/IEC60898
额定电流1~63A
分断能力10000A
极数1,2,3,4
脱扣曲线B,C,D
References Description
A9F27101 iC65H 1P B1A 78.5
A9F27102 iC65H 1P B2A 71.0
A9F27103 iC65H 1P B3A 67.0
A9F27104 iC65H 1P B4A 67.0
A9F27106 iC65H 1P B6A 55.4
A9F27110 iC65H 1P B10A 40.7
A9F27116 iC65H 1P B16A 40.7
A9F27120 iC65H 1P B20A 40.7
A9F27125 iC65H 1P B25A 46.8
A9F27132 iC65H 1P B32A 46.8
A9F27140 iC65H 1P B40A 55.4
Page 4 of 76
A9F27150 iC65H 1P B50A 67.0
A9F27163 iC65H 1P B63A 74.3
A9F27201 iC65H 2P B1A 179.1
A9F27202 iC65H 2P B2A 162.2
A9F27203 iC65H 2P B3A 153.0
A9F27204 iC65H 2P B4A 153.0
A9F27206 iC65H 2P B6A 133.8
A9F27210 iC65H 2P B10A 100.4
A9F27216 iC65H 2P B16A 100.4
A9F27220 iC65H 2P B20A 100.4
A9F27225 iC65H 2P B25A 110.7
A9F27232 iC65H 2P B32A 110.7
A9F27240 iC65H 2P B40A 135.4
A9F27250 iC65H 2P B50A 153.0
A9F27263 iC65H 2P B63A 160.3
A9F27301 iC65H 3P B1A 272.0
A9F27302 iC65H 3P B2A 246.9
A9F27303 iC65H 3P B3A 232.8
A9F27304 iC65H 3P B4A 232.8
A9F27306 iC65H 3P B6A 196.4
A9F27310 iC65H 3P B10A 160.3
A9F27316 iC65H 3P B16A 160.3
A9F27320 iC65H 3P B20A 160.3
A9F27325 iC65H 3P B25A 174.7
A9F27332 iC65H 3P B32A 174.7
A9F27340 iC65H 3P B40A 203.6
A9F27350 iC65H 3P B50A 232.8
A9F27363 iC65H 3P B63A 247.4
A9F27401 iC65H 4P B1A 365.9
A9F27402 iC65H 4P B2A 332.1
A9F27403 iC65H 4P B3A 313.0
A9F27404 iC65H 4P B4A 313.0
A9F27406 iC65H 4P B6A 262.1
A9F27410 iC65H 4P B10A 211.0
A9F27416 iC65H 4P B16A 211.0
A9F27420 iC65H 4P B20A 211.0
A9F27425 iC65H 4P B25A 232.8
A9F27432 iC65H 4P B32A 232.8
A9F27440 iC65H 4P B40A 269.2
A9F27450 iC65H 4P B50A 305.7
A9F27463 iC65H 4P B63A 327.6
A9F28101 iC65H 1P C1A 77.9
A9F28102 iC65H 1P C2A 70.4
A9F28104 iC65H 1P C4A 66.4
A9F28106 iC65H 1P C6A 54.8
A9F28110 iC65H 1P C10A 40.3
A9F28116 iC65H 1P C16A 40.3
A9F28120 iC65H 1P C20A 40.3
A9F28125 iC65H 1P C25A 46.4
A9F28132 iC65H 1P C32A 46.4
A9F28140 iC65H 1P C40A 54.8
A9F28150 iC65H 1P C50A 66.4
A9F28163 iC65H 1P C63A 73.6
Page 5 of 76
A9F28201 iC65H 2P C1A 177.3
A9F28202 iC65H 2P C2A 160.6
A9F28204 iC65H 2P C4A 151.5
A9F28206 iC65H 2P C6A 132.5
A9F28210 iC65H 2P C10A 99.2
A9F28216 iC65H 2P C16A 99.2
A9F28220 iC65H 2P C20A 99.2
A9F28225 iC65H 2P C25A 109.6
A9F28232 iC65H 2P C32A 109.6
A9F28240 iC65H 2P C40A 133.9
A9F28250 iC65H 2P C50A 151.5
A9F28263 iC65H 2P C63A 158.6
A9F28301 iC65H 3P C1A 269.2
A9F28302 iC65H 3P C2A 244.7
A9F28304 iC65H 3P C4A 230.3
A9F28306 iC65H 3P C6A 194.4
A9F28310 iC65H 3P C10A 158.6
A9F28316 iC65H 3P C16A 158.6
A9F28320 iC65H 3P C20A 158.6
A9F28325 iC65H 3P C25A 173.0
A9F28332 iC65H 3P C32A 173.0
A9F28340 iC65H 3P C40A 201.7
A9F28350 iC65H 3P C50A 230.3
A9F28363 iC65H 3P C63A 245.1
A9F28401 iC65H 4P C1A 362.4
A9F28402 iC65H 4P C2A 328.8
A9F28404 iC65H 4P C4A 309.9
A9F28406 iC65H 4P C6A 259.7
A9F28410 iC65H 4P C10A 209.1
A9F28416 iC65H 4P C16A 209.1
A9F28420 iC65H 4P C20A 209.1
A9F28425 iC65H 4P C25A 230.3
A9F28432 iC65H 4P C32A 230.3
A9F28440 iC65H 4P C40A 266.6
A9F28450 iC65H 4P C50A 302.8
A9F28463 iC65H 4P C63A 324.3
A9F29101 iC65H 1P D1A 104.3
A9F29102 iC65H 1P D2A 104.3
A9F29104 iC65H 1P D4A 98.4
A9F29106 iC65H 1P D6A 71.0
A9F29110 iC65H 1P D10A 59.5
A9F29116 iC65H 1P D16A 59.5
A9F29120 iC65H 1P D20A 59.5
A9F29125 iC65H 1P D25A 68.0
A9F29132 iC65H 1P D32A 68.0
A9F29140 iC65H 1P D40A 78.1
A9F29150 iC65H 1P D50A 89.9
A9F29163 iC65H 1P D63A 104.2
A9F29201 iC65H 2P D1A 238.1
A9F29202 iC65H 2P D2A 238.1
A9F29204 iC65H 2P D4A 224.2
A9F29206 iC65H 2P D6A 173.7
A9F29210 iC65H 2P D10A 140.4
Page 6 of 76
A9F29216 iC65H 2P D16A 140.4
A9F29220 iC65H 2P D20A 140.4
A9F29225 iC65H 2P D25A 159.2
A9F29232 iC65H 2P D32A 159.2
A9F29240 iC65H 2P D40A 180.9
A9F29250 iC65H 2P D50A 210.1
A9F29263 iC65H 2P D63A 246.3
A9F29301 iC65H 3P D1A 353.3
A9F29302 iC65H 3P D2A 353.3
A9F29304 iC65H 3P D4A 332.9
A9F29306 iC65H 3P D6A 246.3
A9F29310 iC65H 3P D10A 217.0
A9F29316 iC65H 3P D16A 217.0
A9F29320 iC65H 3P D20A 217.0
A9F29325 iC65H 3P D25A 231.7
A9F29332 iC65H 3P D32A 231.7
A9F29340 iC65H 3P D40A 246.3
A9F29350 iC65H 3P D50A 275.5
A9F29363 iC65H 3P D63A 318.6
A9F29401 iC65H 4P D1A 430.0
A9F29402 iC65H 4P D2A 430.0
A9F29404 iC65H 4P D4A 405.4
A9F29406 iC65H 4P D6A 347.6
A9F29410 iC65H 4P D10A 318.6
A9F29416 iC65H 4P D16A 318.6
A9F29420 iC65H 4P D20A 318.6
A9F29425 iC65H 4P D25A 332.9
A9F29432 iC65H 4P D32A 332.9
A9F29440 iC65H 4P D40A 347.6
A9F29450 iC65H 4P D50A 398.2
A9F29463 iC65H 4P D63A 463.4
iC65L小型断路器
标准GB14048.2/IEC60947.2
额定电流1~63A
分断能力15kA
极数1,2,3,4
脱扣曲线C,D
References Description
A9F38101 iC65L 1P C1A 112.3
A9F38102 iC65L 1P C2A 101.3
A9F38104 iC65L 1P C4A 95.8
A9F38106 iC65L 1P C6A 78.8
A9F38110 iC65L 1P C10A 58.1
A9F38116 iC65L 1P C16A 58.1
A9F38120 iC65L 1P C20A 58.1
A9F38125 iC65L 1P C25A 66.6
A9F38132 iC65L 1P C32A 66.6
A9F38140 iC65L 1P C40A 78.8
A9F38150 iC65L 1P C50A 95.8
A9F38163 iC65L 1P C63A 121.2
Page 7 of 76
A9F38201 iC65L 2P C1A 255.5
A9F38202 iC65L 2P C2A 231.3
A9F38204 iC65L 2P C4A 218.0
A9F38206 iC65L 2P C6A 191.2
A9F38210 iC65L 2P C10A 143.4
A9F38216 iC65L 2P C16A 143.4
A9F38220 iC65L 2P C20A 143.4
A9F38225 iC65L 2P C25A 157.8
A9F38232 iC65L 2P C32A 157.8
A9F38240 iC65L 2P C40A 193.2
A9F38250 iC65L 2P C50A 218.0
A9F38263 iC65L 2P C63A 293.5
A9F38301 iC65L 3P C1A 387.6
A9F38302 iC65L 3P C2A 352.5
A9F38304 iC65L 3P C4A 332.2
A9F38306 iC65L 3P C6A 280.2
A9F38310 iC65L 3P C10A 228.4
A9F38316 iC65L 3P C16A 228.4
A9F38320 iC65L 3P C20A 228.4
A9F38325 iC65L 3P C25A 249.3
A9F38332 iC65L 3P C32A 249.3
A9F38340 iC65L 3P C40A 290.6
A9F38350 iC65L 3P C50A 332.2
A9F38363 iC65L 3P C63A 403.5
A9F38401 iC65L 4P C1A 522.0
A9F38402 iC65L 4P C2A 473.5
A9F38404 iC65L 4P C4A 446.3
A9F38406 iC65L 4P C6A 374.0
A9F38410 iC65L 4P C10A 300.9
A9F38416 iC65L 4P C16A 300.9
A9F38420 iC65L 4P C20A 300.9
A9F38425 iC65L 4P C25A 332.2
A9F38432 iC65L 4P C32A 332.2
A9F38440 iC65L 4P C40A 384.5
A9F38450 iC65L 4P C50A 436.3
A9F38463 iC65L 4P C63A 567.3
A9F39101 iC65L 1P D1A 149.5
A9F39102 iC65L 1P D2A 149.5
A9F39104 iC65L 1P D4A 141.2
A9F39106 iC65L 1P D6A 101.8
A9F39110 iC65L 1P D10A 85.4
A9F39116 iC65L 1P D16A 85.4
A9F39120 iC65L 1P D20A 85.4
A9F39125 iC65L 1P D25A 97.6
A9F39132 iC65L 1P D32A 97.6
A9F39140 iC65L 1P D40A 112.0
A9F39150 iC65L 1P D50A 129.0
A9F39163 iC65L 1P D63A 138.8
A9F39201 iC65L 2P D1A 341.3
A9F39202 iC65L 2P D2A 341.3
A9F39204 iC65L 2P D4A 321.6
A9F39206 iC65L 2P D6A 249.3
A9F39210 iC65L 2P D10A 201.5
Page 8 of 76
A9F39216 iC65L 2P D16A 201.5
A9F39220 iC65L 2P D20A 201.5
A9F39225 iC65L 2P D25A 228.4
A9F39232 iC65L 2P D32A 228.4
A9F39240 iC65L 2P D40A 259.8
A9F39250 iC65L 2P D50A 300.9
A9F39263 iC65L 2P D63A 328.0
A9F39301 iC65L 3P D1A 488.6
A9F39302 iC65L 3P D2A 488.6
A9F39304 iC65L 3P D4A 460.6
A9F39306 iC65L 3P D6A 353.3
A9F39310 iC65L 3P D10A 311.4
A9F39316 iC65L 3P D16A 311.4
A9F39320 iC65L 3P D20A 311.4
A9F39325 iC65L 3P D25A 332.2
A9F39332 iC65L 3P D32A 332.2
A9F39340 iC65L 3P D40A 353.3
A9F39350 iC65L 3P D50A 394.4
A9F39363 iC65L 3P D63A 433.9
A9F39401 iC65L 4P D1A 616.8
A9F39402 iC65L 4P D2A 616.8
A9F39404 iC65L 4P D4A 581.6
A9F39406 iC65L 4P D6A 498.3
A9F39410 iC65L 4P D10A 456.9
A9F39416 iC65L 4P D16A 456.9
A9F39420 iC65L 4P D20A 456.9
A9F39425 iC65L 4P D25A 477.8
A9F39432 iC65L 4P D32A 477.8
A9F39440 iC65L 4P D40A 498.3
A9F39450 iC65L 4P D50A 571.1
A9F39463 iC65L 4P D63A 617.1
iC60L MA单磁式小型断路器
标准GB14048.2/IEC60947.2
额定电流1.6~40A
分断能力15kA
极数2,3
脱扣曲线MA
References Description
A9F90272 iC60LMA 2P 1.6A 235.7
A9F90273 iC60LMA 2P 2.5A 235.7
A9F90204 iC60LMA 2P 4A 222.1
A9F90276 iC60LMA 2P 6.3A 171.9
A9F90210 iC60LMA 2P 10A 139.1
A9F90282 iC60LMA 2P 12.5A 137.8
A9F90216 iC60LMA 2P 16A 139.1
A9F90225 iC60LMA 2P 25A 157.6
A9F90240 iC60LMA 2P 40A 179.2
A9F90372 iC60LMA 3P 1.6A 349.7
A9F90373 iC60LMA 3P 2.5A 349.7
A9F90304 iC60LMA 3P 4A 329.8
Page 9 of 76
A9F90376 iC60LMA 3P 6.3A 243.8
A9F90310 iC60LMA 3P 10A 214.9
A9F90382 iC60LMA 3P 12.5A 212.8
A9F90316 iC60LMA 3P 16A 214.9
A9F90325 iC60LMA 3P 25A 229.5
A9F90340 iC60LMA 3P 40A 243.8
iDPNK2小型断路器
标准GB10963/IEC60898
额定电流1~63A
分断能力6000A
极数1P+N
脱扣曲线C
References Description
A9F18610 iDPNK2 10A 57.1
A9F18616 iDPNK2 16A 57.1
A9F18620 iDPNK2 20A 57.1
A9F18625 iDPNK2 25A 61.4
A9F18632 iDPNK2 32A 61.4
A9F18640 iDPNK2 40A 73.4
A9F18650 iDPNK2 50A 78.9
A9F18663 iDPNK2 63A 84.3
iDPNa小型断路器
标准GB10963/IEC60898
额定电流1~63A
分断能力4500A
极数1P+N
脱扣曲线C
References Description
A9P08606 iDPNa C 6A 4.5KA 56.2
A9P08610 iDPNa C 10A 4.5KA 47.7
A9P08616 iDPNa C 16A 4.5KA 47.7
A9P08620 iDPNa C 20A 4.5KA 47.7
A9P08625 iDPNa C 25A 4.5KA 54.3
A9P08632 iDPNa C 32A 4.5KA 54.3
A9P08640 iDPNa C 40A 4.5KA 62.0
iDPNa-K小型断路器
标准GB10963/IEC60898
额定电流6~32A
分断能力4500A
极数1P+N
脱扣曲线C
References Description
A9P58606 iDPNa-K C 6 53.0
A9P58610 iDPNa-K C 10 44.9
Page 10 of 76
A9P58616 iDPNa-K C 16 44.9
A9P58620 iDPNa-K C 20 44.9
A9P58625 iDPNa-K C 25 51.2
A9P58632 iDPNa-K C 32 51.2
iDPNN小型断路器
标准GB10963/IEC60898
额定电流2~40A
分断能力6000A
极数1P+N
脱扣曲线C
References Description
A9P18602 iDPNN C 2A 6KA 74.1
A9P18606 iDPNN C 6A 6KA 61.6
A9P18610 iDPNN C 10A 6KA 57.1
A9P18616 iDPNN C 16A 6KA 57.1
A9P18620 iDPNN C 20A 6KA 57.1
A9P18625 iDPNN C 25A 6KA 68.6
A9P18632 iDPNN C 32A 6KA 68.6
A9P18640 iDPNN C 40A 6KA 74.1
iDPNH小型断路器
标准GB10963/IEC60898
额定电流2~40A
分断能力10000A
极数1P+N
脱扣曲线C
References Description
A9P28602 iDPNH C 2A 10KA 119.9
A9P28606 iDPNH C 6A 10KA 106.0
A9P28610 iDPNH C 10A 10KA 92.2
A9P28616 iDPNH C 16A 10KA 92.2
A9P28620 iDPNH C 20A 10KA 92.2
A9P28625 iDPNH C 25A 10KA 119.9
A9P28632 iDPNH C 32A 10KA 119.9
A9P28640 iDPNH C 40A 10KA 129.6
适用于iC65,iC60,iDPN 小型断路器及iID剩余电流动作开关的电气附件
References Description
A9A26960 iMN 220-240V 351.1
A9A26961 iMN 48V 351.1
A9A26963 iMNs 220-240V 843.7
A9A26979 iMSU 275V 101.8
A9A26476 iMX 100-415V 276.7
A9A26477 iMX 48V 276.7
A9A26478 iMX 12-24V 276.7
A9A26946 iMX+OF 100-415V 318.5
Page 11 of 76
A9A26947 iMX+OF 48V 318.5
A9A26948 iMX+OF 12-24V 318.5
A9A26924 iOF 90.6
A9A26929 iOF/SD+OF 219.5
A9A26927 iSD 107.0
适用于iC65,iC60,iDPN 小型断路器及iID剩余电流动作开关的机械附件
References Description
A9A27005 黑色手柄166.4
A9A27006 红色手柄166.4
A9A27008 旋转手柄基座（不含手柄） 255.4
A9A27003 断路器插拔式底座223.6
A9A26970 挂锁辅件（1包10个) 354.4
A9A27062 9mm 间隔件（一包5个） 75.2
Vigi iC65剩余电流动作保护附件
标准GB16917/IEC61009
额定电流<=40A <=63A
保护类型AC A
产品类型电子式，电磁式
极数1+N,2,3,4
References Description
A9V53640 Vigi iC65 ELE 1PPN 40A 30mA AC 122.4
A9V53663 Vigi iC65 ELE 1PPN 63A 30mA AC 160.4
A9V53240 Vigi iC65 ELE 2P 40A 30mA AC 122.4
A9V63240 Vigi iC65 ELE 2P 40A 100mA AC 147.1
A9V83240 Vigi iC65 ELE 2P 40A 300mA AC 128.9
A9V93240 Vigi iC65 ELE 2P 40A 300mA-S AC 136.5
A9V53263 Vigi iC65 ELE 2P 63A 30mA AC 160.4
A9V63263 Vigi iC65 ELE 2P 63A 100mA AC 192.4
A9V73263 Vigi iC65 ELE 2P 63A 100mA-S AC 231.1
A9V83263 Vigi iC65 ELE 2P 63A 300mA AC 168.4
A9V93263 Vigi iC65 ELE 2P 63A 300mA-S AC 178.7
A9V50240 Vigi iC65 ELE G 2P 40A 30mA AC 150.5
A9V50263 Vigi iC65 ELE G 2P 63A 30mA AC 238.8
A9V53340 Vigi iC65 ELE 3P 40A 30mA AC 167.3
A9V63340 Vigi iC65 ELE 3P 40A 100mA AC 200.5
A9V83340 Vigi iC65 ELE 3P 40A 300mA AC 175.7
A9V93340 Vigi iC65 ELE 3P 40A 300mA-S AC 186.4
A9V53363 Vigi iC65 ELE 3P 63A 30mA AC 227.2
A9V63363 Vigi iC65 ELE 3P 63A 100mA AC 272.5
A9V73363 Vigi iC65 ELE 3P 63A 100mA-S AC 327.0
A9V83363 Vigi iC65 ELE 3P 63A 300mA AC 238.9
A9V93363 Vigi iC65 ELE 3P 63A 300mA-S AC 252.9
A9V53440 Vigi iC65 ELE 4P 40A 30mA AC 208.7
A9V63440 Vigi iC65 ELE 4P 40A 100mA AC 250.4
A9V83440 Vigi iC65 ELE 4P 40A 300mA AC 219.4
A9V93440 Vigi iC65 ELE 4P 40A 300mA-S AC 232.0
Page 12 of 76
A9V53463 Vigi iC65 ELE 4P 63A 30mA AC 280.8
A9V63463 Vigi iC65 ELE 4P 63A 100mA AC 337.0
A9V73463 Vigi iC65 ELE 4P 63A 100mA-S AC 404.4
A9V83463 Vigi iC65 ELE 4P 63A 300mA AC 295.0
A9V93463 Vigi iC65 ELE 4P 63A 300mA-S AC 312.5
A9V57640 Vigi iC65 ELE 1PPN 40A 30mA A 151.6
A9V57663 Vigi iC65 ELE 1PPN 63A 30mA A 208.6
A9V57240 Vigi iC65 ELE 2P 40A 30mA A 151.6
A9V57263 Vigi iC65 ELE 2P 63A 30mA A 208.6
A9V57340 Vigi iC65 ELE 3P 40A 30mA A 217.5
A9V57363 Vigi iC65 ELE 3P 63A 30mA A 295.3
A9V57440 Vigi iC65 ELE 4P 40A 30mA A 271.3
A9V57463 Vigi iC65 ELE 4P 63A 30mA A 365.1
A9V52225 Vigi iC65 ELM 2P 25A 30mA AC 278.4
A9V52240 Vigi iC65 ELM 2P 40A 30mA AC 300.0
A9V52263 Vigi iC65 ELM 2P 63A 30mA AC 487.2
A9V62263 Vigi iC65 ELM 2P 63A 100mA AC 584.6
A9V82263 Vigi iC65 ELM 2P 63A 300mA AC 584.6
A9V92263 Vigi iC65 ELM 2P 63A 300mA-S AC 701.4
A9V52325 Vigi iC65 ELM 3P 25A 30mA AC 341.1
A9V52340 Vigi iC65 ELM 3P 40A 30mA AC 395.5
A9V52363 Vigi iC65 ELM 3P 63A 30mA AC 598.7
A9V62363 Vigi iC65 ELM 3P 63A 100mA AC 718.5
A9V82363 Vigi iC65 ELM 3P 63A 300mA AC 718.5
A9V92363 Vigi iC65 ELM 3P 63A 300mA-S AC 862.2
A9V52425 Vigi iC65 ELM 4P 25A 30mA AC 403.6
A9V52440 Vigi iC65 ELM 4P 40A 30mA AC 477.1
A9V52463 Vigi iC65 ELM 4P 63A 30mA AC 710.2
A9V62463 Vigi iC65 ELM 4P 63A 100mA AC 852.1
A9V82463 Vigi iC65 ELM 4P 63A 300mA AC 852.1
A9V92463 Vigi iC65 ELM 4P 63A 300mA-S AC 1022.5
Vigi iDPN剩余电流动作保护附件
标准GB16917/IEC61009
额定电流<=25A <=40A
保护类型AC A
产品类型电子式 电磁式(稍晚上市)
极数1+N
References Description
A9Y53625 Vigi DPN ELE 25A (下出线) 90.4
A9Y53640 Vigi DPN ELE 40A (下出线) 98.6
A9Y50640 Vigi DPN G ELE 40A (下出线) 123.2
A9Y57625 Vigi DPN Class A ELE 25A 30mA 113.0
A9Y57640 Vigi DPN Class A ELE 40A 30mA 123.2
A9Y47625 Vigi DPN Class A ELE 25A 10mA 135.6
A9Y47640 Vigi DPN Class A ELE 40A 10mA 147.8
A9Y50625 Vigi DPN G Class A ELE 25A 30mA 139.8
iID剩余电流动作开关
Page 13 of 76
标准GB16916/IEC61008
额定电流25,40,63,80,100A
保护类型AC
产品类型电磁式
额定剩余动作电流10,30,100,300mA
极数2,4
References Description
A9R42225 iID 2P 25A 10mA AC 525.5
A9R52225 iID 2P 25A 30mA AC 352.0
A9R52240 iID 2P 40A 30mA AC 370.6
A9R62240 iID 2P 40A 100mA AC 407.5
A9R82240 iID 2P 40A 300mA AC 378.0
A9R52263 iID 2P 63A 30mA AC 463.2
A9R62263 iID 2P 63A 100mA AC 504.3
A9R82263 iID 2P 63A 300mA AC 487.8
A9R52280 iID 2P 80A 30mA AC 589.5
A9R82280 iID 2P 80A 300mA AC 942.1
A9R52291 iID 2P 100A 30mA AC 643.7
A9R82291 iID 2P 100A 300mA AC 1040.7
A9R52425 iID 4P 25A 30mA AC 506.4
A9R52440 iID 4P 40A 30mA AC 533.4
A9R62440 iID 4P 40A 100mA AC 618.5
A9R82440 iID 4P 40A 300mA AC 518.8
A9R52463 iID 4P 63A 30mA AC 672.5
A9R62463 iID 4P 63A 100mA AC 868.3
A9R82463 iID 4P 63A 300mA AC 738.8
A9R52480 iID 4P 80A 30mA AC 1195.8
A9R82480 iID 4P 80A 300mA AC 1054.7
A9R52491 iID 4P 100A 30mA AC 1211.2
A9R82491 iID 4P 100A 300mA AC 1083.0
iDPN 剩余电流动作保护断路器
标准GB16917/IEC61009
分断能力4.5,6kA
额定电流6~32A(4.5kA);10~25A (6kA)
保护类型AC
产品类型电子式
额定剩余动作电流30mA
References Description
A9D90606 iDPNa Vigi (36mm) 143.5
A9D91610 iDPNa Vigi+ (18mm) 131.4
A9D91616 iDPNa Vigi+ (18mm) 131.4
A9D91620 iDPNa Vigi+ (18mm) 131.4
A9D91625 iDPNa Vigi+ (18mm) 147.5
A9D90632 iDPNa Vigi (36mm) 147.5
A9D95610 iDPNN Vigi+ 140.3
A9D95616 iDPNN Vigi+ 140.3
A9D95620 iDPNN Vigi+ 140.3
A9D95625 iDPNN Vigi+ 151.1
Page 14 of 76
Acti9模块化电涌保护器
References Description
A9L916870 iPR 120r 1P
A9L916800 iPR 65r 1P
A9L916802 iPR 65r 1P+N
A9L916803 iPR 65r 2P
A9L916804 iPR 65r 3P
A9L916806 iPR 65r 3P+N
A9L916807 iPR 65r 4P
A9L916808 iPR 40r 1P
A9L916809 iPR 40 1P
A9L916812 iPR 40r 1P+N
A9L916813 iPR 40 1P+N
A9L916814 iPR 40r 2P
A9L916815 iPR 40 2P
A9L916816 iPR 40r 3P
A9L916817 iPR 40 3P
A9L916820 iPR 40r 3P+N
A9L916821 iPR 40 3P+N
A9L916822 iPR 40r 4P
A9L916823 iPR 40 4P
A9L916844 iPR 20r 1P
A9L916824 iPR 20 1P
A9L916825 iPR 20r 1P+N
A9L916826 iPR 20 1P+N
A9L916847 iPR 20r 2P
A9L916827 iPR 20 2P
A9L916848 iPR 20r 3P
A9L916828 iPR 20 3P
A9L916850 iPR 20r 3P+N
A9L916830 iPR 20 3P+N
A9L916851 iPR 20r 4P
A9L916831 iPR 20 4P
A9L916832 iPR 10 1P
A9L916834 iPR 10 1P+N
A9L916835 iPR 10 2P
A9L916836 iPR 10 3P
A9L916838 iPR 10 3P+N
A9L916839 iPR 10 4P
A9L916865 iPR 80r 1P
A9L916864 iPR 80r 1P NPE
A9L916867 iD120-340
A9L916840 iD65-340
A9L916843 iD40-340
A9L916846 iD20-340
A9L916849 iD10-340
A9L916842 iDGn
A9L916862 iD80-340
A9L916863 iDGn-80
Page 15 of 76
A9L916600 iST 65 1P
A9L916603 iST 65 2P
A9L916604 iST 65 3P
A9L916605 iST 65r 3P+N
A9L916606 iST 65 3P+N
A9L916607 iST 65r 4P
A9L916608 iST 65 4P
A9L916609 iST 40 1P
A9L916611 iST 40 1P+N
A9L916612 iST 40 2P
A9L916613 iST 40 3P
A9L916614 iST 40r 3P+N
A9L916615 iST 40 3P+N
A9L916616 iST 40r 4P
A9L916617 iST 40 4P
A9L916618 iST 20 1P
A9L916620 iST 20 1P+N
A9L916621 iST 20 2P
A9L916622 iST 20 3P
A9L916623 iST 20 3P+N
A9L916624 iST 20 4P
A9L916625 iST 20r 3P+N
A9L916871 iPT 40r 3P+N
A9L916872 iPT 40 3P+N
A9L916873 iPT 40 1P+N
A9L916874 iPT 20r 3P+N
A9L916875 iPT 20 3P+N
A9L916876 iPT 20 1P+N
A9L916885 iD40-385
A9L916886 iD20-385
A9L916887 iDGn PT
A9L16434 PRD DC40r 600PV
A9L16436 PRD DC40r 1000PV
A9L16683 插拔模块 C40 600PV
A9L16692 插拔模块 C40 1000PV
A9L16690 插拔模块 中性极 PV
iCT接触器
产品标准 IEC61095/GB17885
产品认证 CCC CE
产品极数 1,2,3,4
额定电流 16,25,40A,63A,100A
主触点类型 NO, NC , NO+NC
控制电压 12,24,48,130,230VAC
首次推出可手动控制型iCT
References Description
A9C20132 标准接触器 iCT 2NO 24~V 25A 252.6
A9C20134 标准接触器 iCT 4NO 24~V 25A 408.8
A9C20137 标准接触器 iCT 4NC 24~V 25A 450.8
A9C20731 标准接触器 iCT 1NO 230~240V 25A 204.3
Page 16 of 76
A9C20732 标准接触器 iCT 2NO 230~240V 25A 229.1
A9C20736 标准接触器 iCT 2NC 230~240V 25A 247.3
A9C20833 标准接触器 iCT 3NO 220~240V 25A 313.5
A9C20834 标准接触器 iCT 4NO 220~240V 25A 264.9
A9C20837 标准接触器 iCT 4NC 220~240V 25A 279.0
A9C20838 标准接触器 iCT 2NO2NC 220~240V 25A 277.5
A9C20842 标准接触器 iCT 2NO 220~240V 40A 391.4
A9C20843 标准接触器 iCT 3NO 220~240V 40A 427.0
A9C20844 标准接触器 iCT 4NO 220~240V 40A 503.5
A9C20847 标准接触器 iCT 4NC 220~240V 40A 650.3
A9C20862 标准接触器 iCT 2NO 220~240V 63A 695.5
A9C20863 标准接触器 iCT 3NO 220~240V 63A 744.6
A9C20864 标准接触器 iCT 4NO 220~240V 63A 675.4
A9C20867 标准接触器 iCT 4NC 220~240V 63A 759.7
A9C20868 标准接触器 iCT 2NO2NC 220~240V 63A 683.5
A9C20869 标准接触器 iCT 3NO1NC 220~240V 63A 683.5
A9C21732 带手动控制功能的接触器 iCT 2NO 230~240V 25A 252.1
A9C21834 带手动控制功能的接触器 iCT 4NO 220~240V 25A 291.4
A9C21842 带手动控制功能的接触器 iCT 2NO 220~240V 40A 430.5
A9C21844 带手动控制功能的接触器 iCT 4NO 220~240V 40A 553.8
A9C21862 带手动控制功能的接触器 iCT 2NO 220~240V 63A 765.1
A9C21864 带手动控制功能的接触器 iCT 4NO 220~240V 63A 743.0
A9C22712 标准接触器 iCT 2NO 230~240V 16A 228.8
A9C22715 标准接触器 iCT 1NO1NC 230~240V 16A 228.8
A9C22818 标准接触器 iCT 2NO2NC 220~240V 16A 260.4
A9C20882 标准接触器 iCT 2NO 230~240V 100A 1989.5
A9C20884 标准接触器 iCT 4NO 230~240V 100A 2424.4
A9C15914 触头状态指示附件 iACTs 1NO+1NC 102.3
A9C18308 信号控制附件 iACTc 230…240VAC 564.2
A9C18309 信号控制附件 iACTc 24…48VAC 807.6
A9C15415 黄色卡夹68.0
iTL脉冲继电器
产品认证 CCC CE
产品极数 1,2,3,4
额定电流 16A,32A
主触电类型 NO, NC , NO+NC
控制电压 12,24,48,130,230VAC
多种附件可选
References Description
A9C30811 脉冲继电器 iTL16A 1NO 230...240Vac 110Vdc 50-60HZ 223.9
A9C30311 脉冲继电器 iTL16A 1NO 130Vac 48Vdc 50-60HZ 302.9
A9C30211 脉冲继电器 iTL16A 1NO 48Vac 24Vdc 50-60HZ 283.3
A9C30111 脉冲继电器 iTL16A 1NO 24Vac 50-60hz 12Vdc 257.0
A9C30011 脉冲继电器 iTL16A 1NO 12Vac 50-60hz 6Vdc 283.3
A9C30812 脉冲继电器 iTL16A 2NO 230...240Vac 50-60hz 110Vdc 368.9
A9C30312 脉冲继电器 iTL16A 2NO 130Vac 50-60hz 48Vdc 500.5
A9C30212 脉冲继电器 iTL16A 2NO 48Vac 50-60hz 24Vdc 461.0
A9C30112 脉冲继电器 iTL16A 2NO 24Vac 50-60hz 12Vdc 428.1
A9C30012 脉冲继电器 iTL16A 2NO 12Vac 50-60hz 6Vdc 461.0
Page 17 of 76
A9C32816 脉冲继电器扩展附件 iETL16A 1 O-C 1NO 230...240Vac 50-60hz 110Vdc 335.9
A9C32316 脉冲继电器扩展附件 iETL16A 1 O-C 1NO 130Vac 50-60hz 48Vdc 447.9
A9C32216 脉冲继电器扩展附件 iETL16A 1 O-C 1NO 48Vac 50-60hz 24Vdc 415.0
A9C32116 脉冲继电器扩展附件 iETL16A 1 O-C 1NO 24Vac 50-60hz 12Vdc 382.0
A9C32016 脉冲继电器扩展附件 iETL16A 1 O-C 1NO 12Vac 50-60hz 6Vdc 415.0
A9C30315 脉冲继电器 iTLI 16A 1NO 1NC 130Vac 50-60hz 48Vdc 510.3
A9C30015 脉冲继电器 iTLI 16A 1NO 1NC 12Vac 50-60hz 6Vdc 510.3
A9C30831 脉冲继电器 iTL 32A 1NO 230...240Vac 50-60hz 110Vdc 283.3
A9C32836 脉冲继电器扩展附件iETL 32A 1 O-C 1NO 230...240Vac 50-60hz 110Vdc 415.0
A9C32811 带远程指示的脉冲继电器 iTLs 16A 1NO 230...240Vac 50-60hz 110Vdc 401.7
A9C33811 带集中控制的脉冲继电器 iTLc 16A 1NO 230...240Vac 50-60HZ 401.7
A9C33211 带集中控制的脉冲继电器 iTLc 16A 1NO 48Vac 50-60HZ 559.8
A9C33111 带集中控制的脉冲继电器 iTLc 16A 1NO 24Vac 50-60HZ 540.1
A9C34811 带锁存命令的脉冲继电器 iTLm 16A 1NO 230...240Vac 50-60HZ 401.7
A9C15413 脉冲继电器按钮控制附件 iATLz 130-240 Vac 184.4
A9C15409 脉冲继电器集中控制+指示附件 iATLc+s 24-240 Vac 316.1
A9C15410 脉冲继电器多级控制附件 iATLc+c 24-240 Vac 316.1
A9C15412 脉冲继电器步进控制附件 iATL4 230Vac 50-60hz 513.6
RCA 远程控制附件,适用于iC65,iC60,iDPN,
ARA自动重合闸附件，适用于iC65,iC60,iDPN,iID
References Description
A9C70112 不带Ti24接口的电动操作机构RCA，用于iC65 1P,1P+N,2P 1496.7
A9C70114 不带Ti24接口的电动操作机构RCA，用于 iC65 3P,4P 1499.1
A9C70122 带Ti24接口的电动操作机构RCA，用于iC65 1P,1P+N,2P 1646.3
A9C70124 带Ti24接口的电动操作机构RCA，用于iC65 3P,4P 1649.1
A9C70132 自动重合控制附件ARA，用于iC651P,1P+N,2P 2429.2
A9C70134 自动重合控制附件ARA，用于iC653P,4P 2431.6
A9C70332 自动重合控制附件ARA，用于iID 2P iID，4种程序2429.2
A9C70334 自动重合控制附件ARA，用于iID 4P iID，4种程序2431.6
iINT隔离开关
产品标准 GB14048.3
产品认证 CCC CE
产品极数 1,2,3,4
额定电流32~125A
外形尺寸与M9 INT125一致
References Description
A9N15009 iINT 32A 1P 36.2
A9N15010 iINT 32A 2P 77.2
A9N15011 iINT 32A 3P 115.3
A9N15012 iINT 32A 4P 156.0
A9N15013 iINT 63A 1P 51.2
A9N15014 iINT 63A 2P 116.7
A9N15015 iINT 63A 3P 169.2
A9N15016 iINT 63A 4P 208.5
A9N15017 iINT 80A 1P 92.7
Page 18 of 76
A9N15018 iINT 80A 2P 137.6
A9N15019 iINT 40A 4P 190.6
A9N15020 iINT 40A 2P 87.2
A9N15021 iINT 80A 3P 217.7
A9N15022 iINT 80A 4P 349.0
A9N15023 iINT 40A 3P 140.2
A9N15024 iINT 40A 1P 44.1
A9N15057 iINT 125A 1P 187.4
A9N15058 iINT 125A 2P 300.9
A9N15059 iINT 125A 3P 356.3
A9N15060 iINT 125A 4P 671.4
A9N15090 iINT 100A 1P 116.7
A9N15091 iINT 100A 2P 221.4
A9N15092 iINT 100A 3P 300.3
A9N15093 iINT 100A 4P 418.1
A9A15096 OF iSW (iINT NO/NF) 149.9
连线及安装附件
References Description
04040 电缆分配器（上进线） 63A 4P 274.5
04041 电缆分配器（下进线） 63A 4P 274.5
04000 插拔式负载平衡系统Multiclip 4P 80A 594.3
14880 DPN 梳状母排 1P+N 13X18mm 26.2
14890 DPN 梳状母排 1P+N 24X18mm（共2根） 82.9
14881 C65 梳状母排 1P 12X18mm 13.7
14891 C65 梳状母排 1P 24X18mm（共2根） 47.8
14882 C65 梳状母排 2P 12X18mm 27.0
14892 C65 梳状母排 2P 24X18mm（共2根） 75.2
14883 C65 梳状母排 3P 12X18mm 43.4
14893 C65 梳状母排 3P 24X18mm（共2根） 112.9
14884 C65 梳状母排 4P 12X18mm 67.7
14894 C65 梳状母排 4P 24X18mm（共2根） 250.7
14886 1P+N/1P/2P 梳状母排端盖（共40个） 32.8
14887 3P/4P 梳状母排端盖（共40个） 42.7
14888 1P/2P/3P/4P 梳状母排梳齿保护罩（共40个） 72.8
14885 绝缘连接头（共4个） 38.9
Page 19 of 76
Multi9系列微型断路器价格表
Multi 9系列小型断路器及漏电保护附件
C65N 断路器
技术参数
标 准: IEC 60898/GB 10963
脱扣曲线：B/C/D
额定电压：1P AC 230V
2/3/4P
额定电流：1-63A
分断能力：6kA
Reference Description
订货号说明含税单价
917190 C65N 1P B1A 99.6
917191 C65N 1P B2A 62.6
917192 C65N 1P B3A 57.8
917193 C65N 1P B4A 57.8
917194 C65N 1P B6A 48.0
917195 C65N 1P B10A 35.2
917196 C65N 1P B16A 35.2
917197 C65N 1P B20A 35.2
917198 C65N 1P B25A 39.5
917199 C65N 1P B32A 39.5
917200 C65N 1P B40A 48.0
917201 C65N 1P B50A 57.8
917202 C65N 1P B63A 63.5
917203 C65N 2P B1A 228.2
917204 C65N 2P B2A 145.3
917205 C65N 2P B3A 134.0
917206 C65N 2P B4A 134.0
917207 C65N 2P B6A 114.3
917208 C65N 2P B10A 86.3
917209 C65N 2P B16A 86.3
917210 C65N 2P B20A 86.3
917211 C65N 2P B25A 94.7
917212 C65N 2P B32A 94.7
917213 C65N 2P B40A 115.8
917214 C65N 2P B50A 131.2
917215 C65N 2P B63A 139.6
917216 C65N 3P B1A 297.4
917217 C65N 3P B2A 213.9
917218 C65N 3P B3A 197.6
917219 C65N 3P B4A 197.6
917220 C65N 3P B6A 169.4
917221 C65N 3P B10A 136.9
917222 C65N 3P B16A 136.9
Page 20 of 76
917223 C65N 3P B20A 136.9
917224 C65N 3P B25A 148.0
917225 C65N 3P B32A 148.0
917226 C65N 3P B40A 176.3
917227 C65N 3P B50A 197.6
917228 C65N 3P B63A 211.6
917229 C65N 4P B1A 442.6
917230 C65N 4P B2A 290.0
917231 C65N 4P B3A 268.1
917232 C65N 4P B4A 268.1
917233 C65N 4P B6A 225.9
917234 C65N 4P B10A 183.4
917235 C65N 4P B16A 183.4
917236 C65N 4P B20A 183.4
917237 C65N 4P B25A 197.6
917238 C65N 4P B32A 197.6
917239 C65N 4P B40A 232.7
917240 C65N 4P B50A 260.8
917241 C65N 4P B63A 282.2
17867 C65N 1P C1A 63.2
17868 C65N 1P C2A 58.9
17870 C65N 1P C4A 54.6
17871 C65N 1P C6A 45.3
17873 C65N 1P C10A 33.0
17874 C65N 1P C16A 33.0
17875 C65N 1P C20A 33.0
17876 C65N 1P C25A 37.2
17877 C65N 1P C32A 37.2
17878 C65N 1P C40A 45.3
17879 C65N 1P C50A 54.6
17880 C65N 1P C63A 59.8
17881 C65N 2P C1A 142.2
17882 C65N 2P C2A 136.6
17884 C65N 2P C4A 126.0
17885 C65N 2P C6A 107.6
17887 C65N 2P C10A 81.0
17888 C65N 2P C16A 81.0
17889 C65N 2P C20A 81.0
17890 C65N 2P C25A 88.9
17891 C65N 2P C32A 88.9
17892 C65N 2P C40A 108.9
17893 C65N 2P C50A 123.5
17894 C65N 2P C63A 131.5
17895 C65N 3P C1A 212.7
17896 C65N 3P C2A 201.3
17898 C65N 3P C4A 185.9
17899 C65N 3P C6A 159.4
Page 21 of 76
17900 C65N 3P C10A 128.7
17902 C65N 3P C16A 128.7
17903 C65N 3P C20A 128.7
17904 C65N 3P C25A 139.4
17905 C65N 3P C32A 139.4
17906 C65N 3P C40A 165.9
17907 C65N 3P C50A 185.9
17908 C65N 3P C63A 199.2
17909 C65N 4P C1A 284.7
17910 C65N 4P C2A 273.0
17912 C65N 4P C4A 252.4
17913 C65N 4P C6A 212.4
17914 C65N 4P C10A 172.5
17916 C65N 4P C16A 172.5
17917 C65N 4P C20A 172.5
17918 C65N 4P C25A 185.9
17919 C65N 4P C32A 185.9
17920 C65N 4P C40A 219.0
17921 C65N 4P C50A 245.4
17922 C65N 4P C63A 265.4
17924 C65N 1P D1A 84.0
17925 C65N 1P D2A 84.0
17927 C65N 1P D4A 77.5
17928 C65N 1P D6A 55.8
17929 C65N 1P D10A 46.5
17931 C65N 1P D16A 46.5
17932 C65N 1P D20A 46.5
17933 C65N 1P D25A 53.1
17934 C65N 1P D32A 53.1
17935 C65N 1P D40A 61.1
17987 C65N 1P D50A 70.9
17988 C65N 1P D63A 81.7
17936 C65N 2P D1A 191.5
17937 C65N 2P D2A 191.5
17939 C65N 2P D4A 177.0
17940 C65N 2P D6A 136.0
17941 C65N 2P D10A 110.0
17943 C65N 2P D16A 110.0
17944 C65N 2P D20A 110.0
17945 C65N 2P D25A 125.2
17946 C65N 2P D32A 125.2
17947 C65N 2P D40A 142.9
17989 C65N 2P D50A 163.2
17990 C65N 2P D63A 190.4
17948 C65N 3P D1A 280.0
17949 C65N 3P D2A 280.0
17951 C65N 3P D4A 258.5
Page 22 of 76
17952 C65N 3P D6A 190.4
17953 C65N 3P D10A 170.0
17955 C65N 3P D16A 170.0
17956 C65N 3P D20A 170.0
17957 C65N 3P D25A 183.7
17958 C65N 3P D32A 183.7
17959 C65N 3P D40A 190.4
17991 C65N 3P D50A 217.5
17992 C65N 3P D63A 251.9
17960 C65N 4P D1A 346.4
17961 C65N 4P D2A 346.4
17963 C65N 4P D4A 319.7
17964 C65N 4P D6A 272.2
17965 C65N 4P D10A 251.9
17967 C65N 4P D16A 251.9
17968 C65N 4P D20A 251.9
17969 C65N 4P D25A 258.5
17985 C65N 4P D32A 258.5
17986 C65N 4P D40A 272.2
17993 C65N 4P D50A 313.2
17994 C65N 4P D63A 360.8
C65H 断路器
技术参数
标 准: IEC 60898/GB 10963
脱扣曲线: B/C/D
额定电压: 1P
2/3/4P
额定电流: 1-63A
分断能力: 10kA
Reference Description
订货号说明
917500 C65H 1P 1A B 230/400V 10kA 84.2
917501 C65H 1P 2A B 230/400V 10kA 76.1
917502 C65H 1P 3A B 230/400V 10kA 71.7
917503 C65H 1P 4A B 230/400V 10kA 71.7
917504 C65H 1P 6A B 230/400V 10kA 59.3
917505 C65H 1P 10A B 230/400V 10kA 43.6
917506 C65H 1P 16A B 230/400V 10kA 43.6
917507 C65H 1P 20A B 230/400V 10kA 43.6
917508 C65H 1P 25A B 230/400V 10kA 50.1
917509 C65H 1P 32A B 230/400V 10kA 50.1
917510 C65H 1P 40A B 230/400V 10kA 59.3
917511 C65H 1P 50A B 230/400V 10kA 71.7
917512 C65H 1P 63A B 230/400V 10kA 79.7
917513 C65H 2P 1A B 400V 10kA 191.8
917514 C65H 2P 2A B 400V 10kA 173.7
Page 23 of 76
917515 C65H 2P 3A B 400V 10kA 163.8
917516 C65H 2P 4A B 400V 10kA 163.8
917517 C65H 2P 6A B 400V 10kA 143.2
917518 C65H 2P 10A B 400V 10kA 107.4
917519 C65H 2P 16A B 400V 10kA 107.4
917520 C65H 2P 20A B 400V 10kA 107.4
917521 C65H 2P 25A B 400V 10kA 118.5
917522 C65H 2P 32A B 400V 10kA 118.5
917523 C65H 2P 40A B 400V 10kA 145.0
917524 C65H 2P 50A B 400V 10kA 163.8
917525 C65H 2P 63A B 400V 10kA 171.6
917526 C65H 3P 1A B 400V 10kA 291.3
917527 C65H 3P 2A B 400V 10kA 264.5
917528 C65H 3P 3A B 400V 10kA 249.3
917529 C65H 3P 4A B 400V 10kA 249.3
917530 C65H 3P 6A B 400V 10kA 210.4
917531 C65H 3P 10A B 400V 10kA 171.6
917532 C65H 3P 16A B 400V 10kA 171.6
917533 C65H 3P 20A B 400V 10kA 171.6
917534 C65H 3P 25A B 400V 10kA 187.1
917535 C65H 3P 32A B 400V 10kA 187.1
917536 C65H 3P 40A B 400V 10kA 218.2
917537 C65H 3P 50A B 400V 10kA 249.3
917538 C65H 3P 63A B 400V 10kA 265.0
917539 C65H 4P 1A B 400V 10kA 392.0
917540 C65H 4P 2A B 400V 10kA 355.8
917541 C65H 4P 3A B 400V 10kA 335.3
917542 C65H 4P 4A B 400V 10kA 335.3
917543 C65H 4P 6A B 400V 10kA 280.8
917544 C65H 4P 10A B 400V 10kA 226.1
917545 C65H 4P 16A B 400V 10kA 226.1
917546 C65H 4P 20A B 400V 10kA 226.1
917547 C65H 4P 25A B 400V 10kA 249.3
917548 C65H 4P 32A B 400V 10kA 249.3
917549 C65H 4P 40A B 400V 10kA 288.4
917550 C65H 4P 50A B 400V 10kA 327.5
917551 C65H 4P 63A B 400V 10kA 350.8
17570 C65H 1P C1A 80.1
17571 C65H 1P C2A 72.4
17573 C65H 1P C4A 68.3
17574 C65H 1P C6A 56.4
17575 C65H 1P C10A 41.4
17577 C65H 1P C16A 41.4
17578 C65H 1P C20A 41.4
17579 C65H 1P C25A 47.6
17580 C65H 1P C32A 47.6
17581 C65H 1P C40A 56.4
Page 24 of 76
17582 C65H 1P C50A 68.3
17583 C65H 1P C63A 75.7
17584 C65H 2P C1A 182.3
17585 C65H 2P C2A 165.0
17587 C65H 2P C4A 155.7
17588 C65H 2P C6A 136.2
17589 C65H 2P C10A 102.0
17591 C65H 2P C16A 102.0
17592 C65H 2P C20A 102.0
17593 C65H 2P C25A 112.6
17594 C65H 2P C32A 112.6
17595 C65H 2P C40A 137.6
17596 C65H 2P C50A 155.7
17597 C65H 2P C63A 163.1
17643 C65H 3P C1A 276.7
17644 C65H 3P C2A 251.6
17646 C65H 3P C4A 236.8
17747 C65H 3P C6A 199.8
17661 C65H 3P C10A 163.1
17663 C65H 3P C16A 163.1
17664 C65H 3P C20A 163.1
17665 C65H 3P C25A 177.8
17668 C65H 3P C32A 177.8
17669 C65H 3P C40A 207.3
17671 C65H 3P C50A 236.8
17672 C65H 3P C63A 252.0
17673 C65H 4P C1A 372.6
17674 C65H 4P C2A 338.0
17676 C65H 4P C4A 318.6
17677 C65H 4P C6A 267.0
17678 C65H 4P C10A 214.9
17680 C65H 4P C16A 214.9
17681 C65H 4P C20A 214.9
17767 C65H 4P C25A 236.8
17768 C65H 4P C32A 236.8
17769 C65H 4P C40A 274.0
17770 C65H 4P C50A 311.3
17771 C65H 4P C63A 333.3
17772 C65H 1P D1A 107.3
17773 C65H 1P D2A 107.3
17775 C65H 1P D4A 101.2
17776 C65H 1P D6A 73.0
17777 C65H 1P D10A 61.1
17779 C65H 1P D16A 61.1
17780 C65H 1P D20A 61.1
17781 C65H 1P D25A 70.0
17782 C65H 1P D32A 70.0
Page 25 of 76
17783 C65H 1P D40A 80.3
17784 C65H 1P D50A 92.4
17785 C65H 1P D63A 107.2
17786 C65H 2P D1A 244.8
17787 C65H 2P D2A 244.8
17789 C65H 2P D4A 230.5
17790 C65H 2P D6A 178.6
17791 C65H 2P D10A 144.4
17793 C65H 2P D16A 144.4
17794 C65H 2P D20A 144.4
17795 C65H 2P D25A 163.7
17796 C65H 2P D32A 163.7
17797 C65H 2P D40A 186.0
17798 C65H 2P D50A 215.8
17799 C65H 2P D63A 253.2
17800 C65H 3P D1A 363.2
17801 C65H 3P D2A 363.2
17803 C65H 3P D4A 342.3
17804 C65H 3P D6A 253.2
17805 C65H 3P D10A 223.1
17807 C65H 3P D16A 223.1
17808 C65H 3P D20A 223.1
17809 C65H 3P D25A 238.2
17810 C65H 3P D32A 238.2
17811 C65H 3P D40A 253.2
17812 C65H 3P D50A 283.2
17813 C65H 3P D63A 327.4
17814 C65H 4P D1A 442.1
17815 C65H 4P D2A 442.1
17817 C65H 4P D4A 416.8
17818 C65H 4P D6A 357.4
17819 C65H 4P D10A 327.4
17821 C65H 4P D16A 327.4
17822 C65H 4P D20A 327.4
17823 C65H 4P D25A 342.3
17824 C65H 4P D32A 342.3
17825 C65H 4P D40A 357.4
17826 C65H 4P D50A 409.3
17827 C65H 4P D63A 476.4
C65H ICB断路器
技术参数
标 准: IEC 60947-2/GB 14048.2
脱扣特性: 12 In±20%单磁式
额定电压: 1P
2/3/4P
额定电流: 1-40A
分断能力: 10kA
Page 26 of 76
订货号说明
MGN25881 C65H ICB 1P 1A 106.0
MGN25885 C65H ICB 1P 2A 106.0
MGN25889 C65H ICB 1P 4A 100.3
MGN25893 C65H ICB 1P 6A 72.4
MGN25897 C65H ICB 1P 10A 60.6
MGN25901 C65H ICB 1P 16A 60.6
MGN25905 C65H ICB 1P 20A 60.6
MGN25909 C65H ICB 1P 25A 69.3
MGN25913 C65H ICB 1P 32A 69.3
MGN25917 C65H ICB 1P 40A 79.4
MGN25882 C65H ICB 2P 1A 242.3
MGN25886 C65H ICB 2P 2A 242.3
MGN25890 C65H ICB 2P 4A 228.3
MGN25894 C65H ICB 2P 6A 176.7
MGN25898 C65H ICB 2P 10A 143.0
MGN25902 C65H ICB 2P 16A 143.0
MGN25906 C65H ICB 2P 20A 143.0
MGN25910 C65H ICB 2P 25A 162.1
MGN25914 C65H ICB 2P 32A 162.1
MGN25918 C65H ICB 2P 40A 184.2
MGN25883 C65H ICB 3P 1A 359.5
MGN25887 C65H ICB 3P 2A 359.5
MGN25891 C65H ICB 3P 4A 339.0
MGN25895 C65H ICB 3P 6A 250.5
MGN25899 C65H ICB 3P 10A 220.9
MGN25903 C65H ICB 3P 16A 220.9
MGN25907 C65H ICB 3P 20A 220.9
MGN25911 C65H ICB 3P 25A 235.9
MGN25915 C65H ICB 3P 32A 235.9
MGN25919 C65H ICB 3P 40A 250.5
MGN25884 C65H ICB 4P 1A 437.7
MGN25888 C65H ICB 4P 2A 437.7
MGN25892 C65H ICB 4P 4A 412.7
MGN25908 C65H ICB 4P 20A 324.2
C65L 断路器
技术参数
标 准: IEC 60947-2/GB14048.2
脱扣曲线: C/D
额定电压: 1P
2/3/4P
额定电流: 1-63A
分断能力: 15kA
订货号说明
917036 C65L 1P C1A 120.3
Page 27 of 76
917037 C65L 1P C2A 108.6
917038 C65L 1P C4A 102.6
917039 C65L 1P C6A 84.5
917040 C65L 1P C10A 62.2
917041 C65L 1P C16A 62.2
917042 C65L 1P C20A 62.2
917043 C65L 1P C25A 71.4
917044 C65L 1P C32A 71.4
917045 C65L 1P C40A 84.5
917046 C65L 1P C50A 102.6
917047 C65L 1P C63A 129.8
917048 C65L 2P C1A 273.6
917049 C65L 2P C2A 247.7
917050 C65L 2P C4A 233.5
917051 C65L 2P C6A 204.8
917052 C65L 2P C10A 153.6
917053 C65L 2P C16A 153.6
917054 C65L 2P C20A 153.6
917055 C65L 2P C25A 169.0
917056 C65L 2P C32A 169.0
917057 C65L 2P C40A 207.0
917058 C65L 2P C50A 233.5
917059 C65L 2P C63A 314.4
917060 C65L 3P C1A 415.1
917061 C65L 3P C2A 377.6
917062 C65L 3P C4A 355.9
917063 C65L 3P C6A 300.2
917064 C65L 3P C10A 244.7
917065 C65L 3P C16A 244.7
917066 C65L 3P C20A 244.7
917067 C65L 3P C25A 267.0
917068 C65L 3P C32A 267.0
917069 C65L 3P C40A 311.3
917070 C65L 3P C50A 355.9
917071 C65L 3P C63A 432.3
917072 C65L 4P C1A 559.2
917073 C65L 4P C2A 507.2
917074 C65L 4P C4A 478.1
917075 C65L 4P C6A 400.7
917076 C65L 4P C10A 322.3
917077 C65L 4P C16A 322.3
917078 C65L 4P C20A 322.3
917079 C65L 4P C25A 355.9
917080 C65L 4P C32A 355.9
917081 C65L 4P C40A 411.8
917082 C65L 4P C50A 467.3
917083 C65L 4P C63A 607.7
Page 28 of 76
917084 C65L 1P D1A 160.1
917085 C65L 1P D2A 160.1
917086 C65L 1P D4A 151.2
917087 C65L 1P D6A 109.0
917088 C65L 1P D10A 91.5
917089 C65L 1P D16A 91.5
917090 C65L 1P D20A 91.5
917091 C65L 1P D25A 104.6
917092 C65L 1P D32A 104.6
917093 C65L 1P D40A 120.1
917094 C65L 1P D50A 138.2
917095 C65L 1P D63A 148.8
917096 C65L 2P D1A 365.6
917097 C65L 2P D2A 365.6
917098 C65L 2P D4A 344.5
917099 C65L 2P D6A 267.0
917100 C65L 2P D10A 215.8
917101 C65L 2P D16A 215.8
917102 C65L 2P D20A 215.8
917103 C65L 2P D25A 244.7
917104 C65L 2P D32A 244.7
917105 C65L 2P D40A 278.3
917106 C65L 2P D50A 322.3
917107 C65L 2P D63A 351.4
917108 C65L 3P D1A 523.3
917109 C65L 3P D2A 523.3
917110 C65L 3P D4A 493.4
917111 C65L 3P D6A 378.4
917112 C65L 3P D10A 333.5
917113 C65L 3P D16A 333.5
917114 C65L 3P D20A 333.5
917115 C65L 3P D25A 355.9
917116 C65L 3P D32A 355.9
917117 C65L 3P D40A 378.4
917118 C65L 3P D50A 422.5
917119 C65L 3P D63A 464.8
917120 C65L 4P D1A 660.7
917121 C65L 4P D2A 660.7
917122 C65L 4P D4A 623.0
917123 C65L 4P D6A 533.9
917124 C65L 4P D10A 489.4
917125 C65L 4P D16A 489.4
917126 C65L 4P D20A 489.4
917127 C65L 4P D25A 511.8
917128 C65L 4P D32A 511.8
917129 C65L 4P D40A 533.9
917130 C65L 4P D50A 611.8
Page 29 of 76
917131 C65L 4P D63A 661.0
C60 断路器
技术参数
标 准: IEC 60947-2/GB14048.2
脱扣曲线: C/D
额定电压: 1P
2/3/4P
额定电流: 1-63A
分断能力: N:10kA
H:15KA
Reference Description
MGN60862 C60N 1P C1A 143.3
MGN60863 C60N 1P C2A 133.5
MGN60864 C60N 1P C3A 123.6
MGN60865 C60N 1P C4A 123.6
MGN60866 C60N 1P C6A 102.6
MGN60867 C60N 1P C10A 75.0
MGN60868 C60N 1P C16A 75.0
MGN60869 C60N 1P C20A 75.0
MGN60870 C60N 1P C25A 84.4
MGN60871 C60N 1P C32A 84.4
MGN60872 C60N 1P C40A 102.6
MGN60873 C60N 1P C50A 123.6
MGN60874 C60N 1P C63A 135.7
MGN60875 C60N 2P C1A 322.7
MGN60876 C60N 2P C2A 309.8
MGN60877 C60N 2P C3A 286.1
MGN60878 C60N 2P C4A 286.1
MGN60879 C60N 2P C6A 244.0
MGN60880 C60N 2P C10A 183.7
MGN60881 C60N 2P C16A 183.7
MGN60882 C60N 2P C20A 183.7
MGN60883 C60N 2P C25A 201.7
MGN60884 C60N 2P C32A 201.7
MGN60885 C60N 2P C40A 247.0
MGN60886 C60N 2P C50A 280.1
MGN60887 C60N 2P C63A 298.1
MGN60888 C60N 3P C1A 482.3
MGN60889 C60N 3P C2A 456.6
MGN60890 C60N 3P C3A 421.7
MGN60891 C60N 3P C4A 421.7
MGN60892 C60N 3P C6A 361.4
MGN60893 C60N 3P C10A 292.0
Page 30 of 76
MGN60894 C60N 3P C16A 292.0
MGN60895 C60N 3P C20A 292.0
MGN60896 C60N 3P C25A 316.1
MGN60897 C60N 3P C32A 316.1
MGN60898 C60N 3P C40A 376.4
MGN60899 C60N 3P C50A 421.7
MGN60900 C60N 3P C63A 451.8
MGN60901 C60N 4P C1A 645.8
MGN60902 C60N 4P C2A 619.4
MGN60903 C60N 4P C3A 572.4
MGN60904 C60N 4P C4A 572.4
MGN60905 C60N 4P C6A 481.8
MGN60906 C60N 4P C10A 391.5
MGN60907 C60N 4P C16A 391.5
MGN60908 C60N 4P C20A 391.5
MGN60909 C60N 4P C25A 421.7
MGN60910 C60N 4P C32A 421.7
MGN60911 C60N 4P C40A 496.8
MGN60912 C60N 4P C50A 556.8
MGN60913 C60N 4P C63A 602.1
MGN60506 C60N 1P D1A 190.5
MGN60507 C60N 1P D2A 190.5
MGN60508 C60N 1P D3A 175.9
MGN60589 C60N 1P D4A 175.9
MGN60509 C60N 1P D6A 126.6
MGN60510 C60N 1P D10A 105.3
MGN60511 C60N 1P D16A 105.3
MGN60512 C60N 1P D20A 105.3
MGN60513 C60N 1P D25A 120.5
MGN60514 C60N 1P D32A 120.5
MGN60515 C60N 1P D40A 138.6
MGN60518 C60N 2P D1A 434.2
MGN60519 C60N 2P D2A 434.2
MGN60520 C60N 2P D3A 401.6
MGN60590 C60N 2P D4A 401.6
MGN60521 C60N 2P D6A 308.5
MGN60522 C60N 2P D10A 249.7
MGN60523 C60N 2P D16A 249.7
MGN60524 C60N 2P D20A 249.7
MGN60525 C60N 2P D25A 284.2
MGN60526 C60N 2P D32A 284.2
MGN60527 C60N 2P D40A 323.9
MGN60530 C60N 3P D1A 635.2
Page 31 of 76
MGN60531 C60N 3P D2A 635.2
MGN60532 C60N 3P D3A 586.6
MGN60533 C60N 3P D4A 586.6
MGN60534 C60N 3P D6A 432.0
MGN60535 C60N 3P D10A 385.6
MGN60536 C60N 3P D16A 385.6
MGN60537 C60N 3P D20A 385.6
MGN60538 C60N 3P D25A 416.8
MGN60539 C60N 3P D32A 416.8
MGN60540 C60N 3P D40A 432.0
MGN60543 C60N 4P D1A 785.7
MGN60544 C60N 4P D2A 785.7
MGN60545 C60N 4P D3A 725.4
MGN60546 C60N 4P D4A 725.4
MGN60547 C60N 4P D6A 617.6
MGN60548 C60N 4P D10A 571.2
MGN60549 C60N 4P D16A 571.2
MGN60550 C60N 4P D20A 571.2
MGN60551 C60N 4P D25A 586.6
MGN60552 C60N 4P D32A 586.6
MGN60553 C60N 4P D40A 617.6
MGN60608 C60H 1P C1A 181.4
MGN60609 C60H 1P C2A 164.0
MGN60610 C60H 1P C3A 154.7
MGN60611 C60H 1P C4A 154.7
MGN60612 C60H 1P C6A 127.9
MGN60613 C60H 1P C10A 94.0
MGN60614 C60H 1P C16A 94.0
MGN60615 C60H 1P C20A 94.0
MGN60616 C60H 1P C25A 108.0
MGN60617 C60H 1P C32A 108.0
MGN60618 C60H 1P C40A 127.9
MGN60621 C60H 2P C1A 413.5
MGN60622 C60H 2P C2A 374.4
MGN60623 C60H 2P C3A 353.2
MGN60624 C60H 2P C4A 353.2
MGN60625 C60H 2P C6A 309.0
MGN60626 C60H 2P C10A 231.6
MGN60627 C60H 2P C16A 231.6
MGN60628 C60H 2P C20A 231.6
MGN60629 C60H 2P C25A 255.6
MGN60630 C60H 2P C32A 255.6
MGN60631 C60H 2P C40A 312.4
Page 32 of 76
MGN60634 C60H 3P C1A 627.7
MGN60635 C60H 3P C2A 570.4
MGN60636 C60H 3P C3A 537.3
MGN60637 C60H 3P C4A 537.3
MGN60638 C60H 3P C6A 453.5
MGN60639 C60H 3P C10A 369.9
MGN60640 C60H 3P C16A 369.9
MGN60641 C60H 3P C20A 369.9
MGN60642 C60H 3P C25A 403.3
MGN60643 C60H 3P C32A 403.3
MGN60644 C60H 3P C40A 470.3
MGN60647 C60H 4P C1A 844.9
MGN60648 C60H 4P C2A 766.7
MGN60649 C60H 4P C3A 722.8
MGN60650 C60H 4P C4A 722.8
MGN60651 C60H 4P C6A 605.4
MGN60652 C60H 4P C10A 487.4
MGN60653 C60H 4P C16A 487.4
MGN60654 C60H 4P C20A 487.4
MGN60655 C60H 4P C25A 537.3
MGN60656 C60H 4P C32A 537.3
MGN60657 C60H 4P C40A 621.7
MGN25080 C60H 1P D1A 243.2
MGN25081 C60H 1P D2A 243.2
MGN25082 C60H 1P D3A 229.6
MGN25083 C60H 1P D4A 229.6
MGN25084 C60H 1P D6A 165.7
MGN25085 C60H 1P D10A 138.6
MGN25086 C60H 1P D16A 138.6
MGN25087 C60H 1P D20A 138.6
MGN25088 C60H 1P D25A 158.8
MGN25089 C60H 1P D32A 158.8
MGN25090 C60H 1P D40A 181.9
MGN25108 C60H 2P D1A 555.2
MGN25111 C60H 2P D2A 555.2
MGN25112 C60H 2P D3A 523.0
MGN25113 C60H 2P D4A 523.0
MGN25114 C60H 2P D6A 405.0
MGN25115 C60H 2P D10A 327.5
MGN25117 C60H 2P D16A 327.5
MGN25118 C60H 2P D20A 327.5
MGN25119 C60H 2P D25A 371.3
MGN25120 C60H 2P D32A 371.3
MGN25121 C60H 2P D40A 422.1
Page 33 of 76
MGN25124 C60H 3P D1A 823.7
MGN25125 C60H 3P D2A 823.7
MGN25126 C60H 3P D3A 776.6
MGN25127 C60H 3P D4A 776.6
MGN25128 C60H 3P D6A 574.2
MGN25129 C60H 3P D10A 506.2
MGN25131 C60H 3P D16A 506.2
MGN25132 C60H 3P D20A 506.2
MGN25133 C60H 3P D25A 540.3
MGN25134 C60H 3P D32A 540.3
MGN25135 C60H 3P D40A 574.2
MGN25138 C60H 4P D1A 1003.0
MGN25139 C60H 4P D2A 1003.0
MGN25140 C60H 4P D3A 945.6
MGN25141 C60H 4P D4A 945.6
MGN25142 C60H 4P D6A 810.8
MGN25143 C60H 4P D10A 742.6
MGN25145 C60H 4P D16A 742.6
MGN25146 C60H 4P D20A 742.6
MGN25147 C60H 4P D25A 776.6
MGN25148 C60H 4P D32A 776.6
MGN25149 C60H 4P D40A 810.8
Vigi C65 漏电保护附件
技术参数
标 准: IEC 61009/GB 16917
额定电压: AC 230/400V
额定电流: ELE In≤40A, In≤63A
ELM In≤32A, In≤40A, In≤63A
额定剩余动作电流：30mA/AC类,30mA/A类,300mA/AC类,100mA/AC类
Reference Description
订货号说明
Vigi C65 ELE 漏电保护附件(30mA)
17301 Vigi C65 1P+N 40A ELE 125.8
17435 Vigi C65 1P+N 63A ELE 164.8
17302 Vigi C65 2P 40A ELE 125.8
17436 Vigi C65 2P 63A ELE 164.8
17303 Vigi C65 3P 40A ELE 171.9
17437 Vigi C65 3P 63A ELE 233.5
17304 Vigi C65 4P 40A ELE 214.5
17438 Vigi C65 4P 63A ELE 288.7
Vigi C65 ELE G 具有过压保护的漏电附件(30mA)
17311 Vigi C65 G 1P+N 40A ELE 154.7
Page 34 of 76
17445 Vigi C65 G 1P+N 63A ELE 245.4
17312 Vigi C65 G 2P 40A ELE 154.7
17446 Vigi C65 G 2P 63A ELE 245.4
Vigi C65 ELM 漏电保护附件(30mA)
17472 Vigi C65 2P 32A ELM 286.3
17322 Vigi C65 2P 40A ELM 308.4
17476 Vigi C65 2P 63A ELM 500.9
17473 Vigi C65 3P 32A ELM 350.6
17323 Vigi C65 3P 40A ELM 406.5
17477 Vigi C65 3P 63A ELM 615.4
17474 Vigi C65 4P 32A ELM 415.0
17324 Vigi C65 4P 40A ELM
